TMC-7500 (Drop in Replacement for 3M™ Novec™ 7500) **Passed 3rd Party – TMC Industries, Inc.

Zoom the image with the mouse

TMC-7500 (Drop in Replacement for 3M™ Novec™ 7500) **Passed 3rd Party Laboratory Testing: Non Detectable PFAS**

Out of stock
3M™ Replacement Fluid
7500-12
$1,125.96
* Size

$1,125.96
  customers are viewing this product

TMC-7500 Fluid is a clear, colorless, and nonflammable fluid. TMC-7500 Engineering Fluid is chemically inert and thermally stable. It is a viable option for replacing perfluorocarbons and perfluoropolythers in many industrial applications.

Features

  • Replacement for 3MTM NOVECTM 7500
  • Low Global Warming Potential (GWP)
  • ZERO Ozone Depletion Potential (ODP)
  • Miscible with Novec™ 7500
  • Non-Flammable
  • No Flash Point
  • Wide liquid Range
  • Low Toxicity
  • VOC-exempt solvent (US EPA)
  • RoHS Compliant

Entry 68 of Regulation (EU) 2021/1297 amending Annex XVII of REACH Regulation (EC) No 1907/2006

European Regulation POPs (EU) 2020/784 amending Regulation (EU) 2019/1021

Applications

TMC-7500 is intended to replace ozone-depleting and high global warming potential chemicals for the following suggested industrial and electronic applications:

  • Cooling fluid for semiconductor and electronic devise manufacture process, testing equipment, and facilities
  • Heat transfer fluid
  • Direct contact cooling fluid for supercomputers, high voltage transformers, and power electronic
  • Cooling fluid, special solvent, and process aid for chemical manufacture process
  • Pharmaceutical manufacture process cooling liquid and freezing dry fluid
  • Lubricant Deposition

 Physical Properties

Molecular Formula

CF3CF(CF3)-CF(OC2H5)-CF2CF2CF3

Molecular Weight

414(g/mol)

CAS Number

297730-93-9

Boiling Point

129°C

Surface Tension

16 dynes/cm

Solubility in Water

<5ppm

Flash Point

None

Dielectric Constant

5.8

Viscosity

0.8 centipoise at 25°C

Viscosity, Kinematic, at 25°C, cSt, ASTM D 445.a,cSt

0.79

Thermal Conductiity @25°C, ASTM D 2717, W/m.K

<10

*All values above chart @ 25°C unless otherwise specified.

Physical Properties

Melting Point

-100°C

Pour Point, ASTM D97, °F

<-100

Dielectric Breakdown Voltage, VDE Electrodes, ASTM D 1816, kV

40

Vapor Pressure - Temperature @100°C, ASTM D 2879, psia

0.436

Vapor Pressure - Temperature of Liquids by Isoteiscope @100°F, ASTM 4052, g/cm3

1.6219

Density

1.62 g/ml [@ 20°C]

Specific Gravity

1.62 [Ref Std: WATER=1]

Viscosity @40°C, ASTM D 7042, cP

1.046

Viscosity @100°C, ASTM D 7042, cP

0.525

Viscosity, Kinematic, at -20°C, cSt, ASTM D 445.a, cSt

1.61

Viscosity, Kinematic, at 0°C, cSt, ASTM D 445.a, cSt

1.26


Specifications

Appearance

Clear colorless liquid

Purity (Methoxy Nonafluorobutane)

99.5% Min.


Environmental Properties

Ozone Depletion Potential (ODP)

0.00

Global Warming Potential (GWP)

90

Atmospheric Lifetime (years)

2.2

Volatile Organic Compounds (VOC)

No


Item No.

Test Items

Test Results

Units

Test Method

1





Kinematic Viscosity





-60℃           10.95     mm2/s


-50℃           6.121     mm2/s


-40℃           3.897     mm2/s


-30℃           2.681     mm2/s



ASTM D445-21e2


Item No.

Test Items

Test Results

Units

Test Method

2





Thermal Conductivity





-80℃           0.111      W/mK


-70℃           0.116       W/mK


-60℃           0.117       W/mK


-50℃           0.120       W/mK


-40℃           0.106       W/mK


-30℃           0.086       W/mK

ASTM E1461-13


Kinematic Viscosity TMC-7500

Temperature (°C)

-20

-10

0

10

20

30

40

50

60

70

80

Viscosity (cSt)

1.98

1.69

1.38

1.08

0.85

0.72

0.64

0.56

0.49

0.44

0.41

Thermal Conductivity TMC-7500

Temperature (°C)

-10

0

10

20

30

40

50

60

70

80

Thermal Conductivity (W/m.K)

0.0733

0.0725

0.0715

0.0701

0.0693

0.0679

0.0668

0.0656

0.0645

0.064


Materials Compatibility

TMC-7500 is compatible with most metals, polymers, and plastics.

Recycle and Reclaim Options

TMC Industries, Inc. reclaim service provides significant savings over the cost of new fluid and helps protect the environment by drastically reducing the amount of your waste stream.

Reduce your hazardous waste disposal and achieve better environmental stewardship. TMC Industries, Inc. properly disposes of the contaminants.

Quality Assurances

We guarantee our reclaimed solvents have new qualities and performance capabilities. To support our confidence, pre- and post-processing analytical data accompanies each shipment.

Save on Disposal Costs

Reduce your hazardous waste disposal. Have TMC Industries reclaim your contaminated fluids to their original state and purity and return them to you at about 1/3 the cost of replacing them with new fluids.

Safety, Storage, and Handling

TMC-7500 is nonflammable and does not exhibit flammability characteristics under normal storage conditions. Store in a tightly closed original container. This fluid is highly resistant to thermal breakdown and hydrolysis in storage and during use. Please read the Safety Data Sheet for additional information.
