Combined Lubricant and Corrosion Prevention Compound
MIL-DTL-87177B (revised MIL-L-87177A) Type I, Grade B
A proprietary formulation containing extremely long-lasting anti corrosion inhibitors, which also give superior lubrication coefficients and protect components against moisture. This unique, water displacing lubricant, with synthetic corrosion prevention compounds is tested and proven non-flammable and environmentally friendly without sulphates, chlorides, or other halogens.
Unexcelled in preventing corrosion and contamination on all surfaces in mechanical close tolerance slow moving components, electrical and electronic equipment, used in humid conditions or exposed to salt water.
Can be used on any metal surfaces to prevent galvanic and fretting corrosion as well as other types of corrosion including uniform, pitting and microbial corrosion. Forms a super thin, hydrophobic, non-flammable lubricant film with anti-corrosion properties approximately 7 microns (0.00028 inch) in thickness and is compliant with U.S. EPA regulations, the European Union RoHS Directives and meets MIL-DTL-87177B (Revised MIL-L-87177A) specifications.
SuperCORR A has the following unique combination of properties:
- Displaces both fresh and saltwater moisture
- Non-toxic, Non-flammable and Non-hazardous
- Has a decomposition temperature of 550°F
- Will not freeze or harden, retains properties even in high altitude applications
- Is extremely resistant to air-drying
- Does not attract contaminants
- Is inert and will not increase or decrease contact resistance
- Eliminates surface static electricity, Corona and other electro migration problems in electronic circuit boards and connectors
- Protects against wear, moisture, general and fretting corrosion
- Non-reactive to most plastics
- Forms an airtight seal preventing damage to electronics and other surfaces caused by exposure to acid gases such as Sulfur dioxide (SO2), Nitrogen dioxide (NO2), Hydrogen Sulfide (H2S), Ammonia (NH3), Chlorine based gases (CL12), and the thermal decomposition by product of HFC-227ea used in fire suppression systems, Hydrogen Fluoride (HF)
NOTE: SuperCORR A is to be applied as a preventative measure and will not remove corrosion from an already corroded component or substrate.
A range of corrosion prevention uses and applications
SuperCORR A is designed to protect and lubricate connectors, terminations and electrical bonds and grounds, relays, fittings, circuit boards, computers, and all forms of avionics such as: controls, radios, transponders, RDF, VOR, DME, GPS, radars, storm scope, flight control computers from moisture, general and fretting corrosion, surface static electricity, corona, and other electro migration problems. Other areas of application include Passenger Master Control Panels, fuel shut-off valves LRUs - flap jack screws, flap tracks, actuators, hydraulic line B-nuts, fuel bladder rails, interior and exterior light sockets, antenna interfacing and any exposed metal surfaces. Use anywhere dissimilar metals may come in contact.
Eliminates electrical resistance failures caused by general and fretting corrosion and to lubricate connectors, nano, micro, and conventional electrical switches, terminal blocks and Busbars, electrical bonds and grounds, relays and switching systems, multi-pin cable connectors, interior and exterior light sockets, plugs, connectors, jacks, and receptacles, as well as electronic printed circuits and microminiature circuits.
The corrosion inhibitor will also protect electrical motors, electronics and switches against surface static electricity, corona, and other electro migration problems and uses a fast evaporating nontoxic and environmentally acceptable carrier fluid that is non-reactive to most plastics. Approved in US Tri-service corrosion manuals and military, civilian and aircraft manufacturers, railway, and transport operators worldwide.
Electronic circuitry, connectors and components, computers, electrical motors, relays and terminals ; Avionics - controls, radio, transponder, RDF, VOR, DME, GPS, radar, storm scope, flight control computer, light sockets and antenna interfacing; storage batteries; Passenger Master Control Panel, fuel shut-off valves - LRUs, flap jack screws, flap tracks, actuators, hydraulic line B-nuts, fuel bladder rails, and any exposed metal surfaces.
Corrosion protection for a range of industries
SuperCORR A IS USED BY THE MILITARY, MANUFACTURING AND SERVICE INDUSTRIES: Army, navy and air force, electronic component manufacturers, computer repair companies, meter and instrumentation manufacturers, aircraft manufacture and repair facilities, naval construction and repair facilities, electrical motors and fixtures, electronic sign manufacturing and maintenance companies, and many others.
INDUSTRY APPROVAL FROM: NASA, Boeing Aircraft, Bombardier, Embraer, Lear, Gulfstream, Hawker-Beechcraft, Cessna, Raytheon, Polish Air Force, Northrop-Grumman, Royal Navy and Royal Norwegian Air Force.
