About
Flutec PP1 is used widely to replace 3M™ Fluorinert™ Electronic Liquid FC-72 in gross leak testing, immersion cooling, and heat transfer applications. Flutec PP1 is REACH Certified.
APPLICATIONS
- Heat Transfer
- Electronics Manufacturing
- Precision Cleaning
- Gross Leak Testing
PHYSICAL PROPERTIES COMPARISON
|
|
3M FC-72 |
Flutec PP1 |
|
Appearance |
Clear Colorless |
Clear Colorless |
|
Molecular Weight |
338 |
338 |
|
Boiling Point (1 atm) |
56 oC |
57 oC |
|
Pour Point |
-90 oC |
-90 oC |
|
Estimated Critical Temperature |
449K |
451K |
|
Estimated Critical Pressure |
1.83 x 106 pascals |
1.834 x 106 pascals |
|
Vapor Pressure |
30.9 x 103 pascals |
29.4 x 103 pascals |
|
Latent Heat of Vaporization (at normal boiling pt) |
88J/g |
85.5 J/g |
|
Liquid Density |
1680 kg/m3 |
1682 kg/m3 |
|
Kinematic Viscosity |
0.38 centistokes |
0.39 centistokes |
|
Absolute Viscosity |
0.64 centipoise |
0.656 centipoise |
|
Liquid Specific heat |
1100 J kg-1 C-1 |
1090 J kg-1 C-1 |
|
Liquid Thermal Conductivity |
0.057 W m-1 oC-1 |
.065 W m-1 oC-1 |
|
Co-efficient of Expansion |
0.00156 oC-1 |
0.00159 oC-1 |
|
Surface Tension |
10 dynes/cm |
11.1 dynes/cm |
|
Refractive Index |
1.251 |
1.2564 |
|
Water Solubility |
10 ppm |
10 ppm |
|
Solubility in Water |
<5 ppm |
<0.1 ppm |
|
Ozone Depletion Potential (ODP) |
0 |
0 |
|
Dielectric Strength |
38 kV, 0.1” gap |
>16 kV/mm |
|
Dielectric Constant |
1.75 |
|
|
Electrical Resistivity |
1015 ohm cm |
> 1013 ohm.cm |
PERFORMANCE
Dynamic Viscosity
|
TEMPERATURE (°C) |
RESULT (mPa s) |
|
-100 |
21.5 |
|
-80 |
7.5 |
|
-60 |
3.6 |
|
-40 |
2.15 |
|
-20 |
1.5 |
|
0 |
0.99 |
|
20 |
0.72 |
|
40 |
0.54 |
|
60 |
0.41 |
|
80 |
0.32 |
|
100 |
0.257 |
|
115 |
0.22 |
Density
| TEMPERATURE (°C) | DENSITY (g/ml) |
| 10 | 1.7610 |
| 20 | 1.7326 |
| 30 | 1.7031 |
| 40 | 1.6728 |
| 50 | 1.6410 |
Thermal Conductivity of the Vapor (mW/m/K) PP1
| 0 | 6.1 |
| 20 | 7.9 |
| 40 | 9.6 |
| 60 | 11.3 |
| 80 | 13.1 |
| 100 | 14.8 |
| 120 | 16.6 |
| 140 | 18.3 |
| 160 | 20.1 |
| 180 | 21.8 |
| 200 | 23.5 |
| 220 | 25.3 |
| 240 | 27.0 |
MATERIAL COMPATIBILITY
Compatible with most construction materials.
SAFETY, HANDLING AND STORAGE
Although Flutec PP1 is considered biologically and chemically inert, good laboratory practice should be observed when handling. Flutec PP1 has an indefinite shelf life if properly stored in its original sealed container. Safety data sheets are available on request.
ENVIRONMENTAL
This product has a global warming potential of greater than 150
TSCA - This product is registered on the TSCA inventory under cas number: 86508-42-1 - perfluorocompounds C5-C18. This is a registration for a class 2 substance within the UVCB group. (Variable composition)
VOC – PP1 although Volatile does not classify as a VOC under the current EPA definition of " Volatile organic compounds (VOC) means any compound of carbon, excluding carbon monoxide, carbon dioxide, carbonic acid, metallic carbides or carbonates, and ammonium carbonate, which participates in atmospheric photochemical reactions.
PFAS – There is no current internationally agreed definition of PFAS. The current ECHA & EPA definition is substances containing one fully fluorinated methyl group (-CF3) or fully fluorinated methylene group (-CF2-) without any hydrogen, chlorine, bromine or iodine atom attached to it.
Under this ‘family’ definition Flutec fluids are classified as PFAS products, however, they do not have the properties of concern that functional PFAS products have. Flutec PP1 is NOT toxic and it does NOT Bioaccumulate.
F-gas : this item is included in the f-gas regulations April 2024.
DISPOSAL & RECYCLING
