About
AD-7500 is a direct replacement for 3M Novec 7500 offering the same chemistry and physical properties. AD-7500 is also offered under the trade names Electronic Fluorinated Fluid PFE-50 & TF-7500 in various parts of the world.
AD-7500 possesses many of the inert and dielectric properties of perfluorocarbons (PFCs) and perfluoropolyethers (PFPEs), making them suitable for many single-phase heat transfer applications in the semiconductor manufacturing industry.
PHYSICAL PROPERTIES
| Form: | Liquid |
| Color: | Colorless |
| Odor: | None |
| Molecular Weight: | 414 g/mol |
| pH: | Not Applicable |
| Liquid Density: | 1.62 g/cm³ (68 °F) |
| Kinematic Viscosity: | 0.8 cPs |
| Boiling Point: | 129°C |
| Melting Point: | -100°C |
| Pour Point: | -100°C |
| Evaporation Rate: | |
| Flash Point: | None |
| Flammability: | Not Applicable |
| Dielectric Strength: | >35 kV |
| Dielectric Constant: | 5.8 @1kHz |
| Vapor Pressure: | 2 kPa (25 °C) |
| Latent Heat of Vaporization: | 88.5 |
| Surface Tension: | No Data Available |
| Water Solubility: | No Data Available |
| Solubility in Water: | No Data Available |
| Ozone Depletion Potential (ODP): | 0 |
| Global Warming Potential (GWP): |
90 |
Kinematic Viscosity
| Temperature (°C) |
Result (cSt) |
| -60 | 10.95 |
| -50 |
6.121 |
| -40 |
3.897 |
| -30 |
2.681 |
| -20 |
1.98 |
| -10 |
1.69 |
| 0 |
1.38 |
| 10 |
1.08 |
| 20 |
0.85 |
| 30 |
0.72 |
| 40 |
0.64 |
| 50 |
0.56 |
| 60 |
0.49 |
| 70 |
0.44 |
| 80 |
0.41 |
Thermal Conductivity
| Temperature (°C) |
Result (W/m.K) |
| -80 |
0.111 |
| -70 |
0.116 |
| -60 |
0.117 |
| -50 |
0.120 |
| -40 |
0.106 |
| -30 |
0.086 |
| -10 |
0.0733 |
| 0 |
0.0725 |
| 10 |
0.0715 |
| 20 |
0.0701 |
| 30 |
0.0693 |
| 40 |
0.0679 |
| 50 |
0.0668 |
| 60 |
0.0656 |
| 70 |
0.0645 |
| 80 |
0.064 |
AD-7500 is a direct replacement for 3M Novec 7500 offering the same chemistry and physical properties. AD-7500 is also offered under the trade names Electronic Fluorinated Fluid PFE-50 & TF-7500 in various parts of the world.
AD-7500 possesses many of the inert and dielectric properties of perfluorocarbons (PFCs) and perfluoropolyethers (PFPEs), making them suitable for many single-phase heat transfer applications in the semiconductor manufacturing industry.
PHYSICAL PROPERTIES
| Form: | Liquid |
| Color: | Colorless |
| Odor: | None |
| Molecular Weight: | 414 g/mol |
| pH: | Not Applicable |
| Liquid Density: | 1.62 g/cm³ (68 °F) |
| Kinematic Viscosity: | 0.8 cPs |
| Boiling Point: | 129°C |
| Melting Point: | -100°C |
| Pour Point: | -100°C |
| Evaporation Rate: | |
| Flash Point: | None |
| Flammability: | Not Applicable |
| Dielectric Strength: | >35 kV |
| Dielectric Constant: | 5.8 @1kHz |
| Vapor Pressure: | 2 kPa (25 °C) |
| Latent Heat of Vaporization: | 88.5 |
| Surface Tension: | No Data Available |
| Water Solubility: | No Data Available |
| Solubility in Water: | No Data Available |
| Ozone Depletion Potential (ODP): | 0 |
| Global Warming Potential (GWP): |
90 |
Kinematic Viscosity
| Temperature (°C) |
Result (cSt) |
| -60 | 10.95 |
| -50 |
6.121 |
| -40 |
3.897 |
| -30 |
2.681 |
| -20 |
1.98 |
| -10 |
1.69 |
| 0 |
1.38 |
| 10 |
1.08 |
| 20 |
0.85 |
| 30 |
0.72 |
| 40 |
0.64 |
| 50 |
0.56 |
| 60 |
0.49 |
| 70 |
0.44 |
| 80 |
0.41 |
Thermal Conductivity
| Temperature (°C) |
Result (W/m.K) |
| -80 |
0.111 |
| -70 |
0.116 |
| -60 |
0.117 |
| -50 |
0.120 |
| -40 |
0.106 |
| -30 |
0.086 |
| -10 |
0.0733 |
| 0 |
0.0725 |
| 10 |
0.0715 |
| 20 |
0.0701 |
| 30 |
0.0693 |
| 40 |
0.0679 |
| 50 |
0.0668 |
| 60 |
0.0656 |
| 70 |
0.0645 |
| 80 |
0.064 |
AD-7500 FLUORINATED ENGINEERING FLUID
Translation missing: en.products.product.sku:7570-11
- Regular price
- $1,570.36
- Sale price
- $1,570.36
- Regular price
-
Shipping Policy
Shipping Policy
Return Policy
Return Policy
Manufacturer P/N:
CAS#: 297730-93-9
Harmonized Tariff#: 2909.19
Schedule B#: 2909.19.0000
ECCN#: EAR99 EC/List#:
UFI#:
Index#:
EU-REACH#:
K-REACH#:
Trade Description: Fluorinated Heat Transfer Fluid
Country of Origin: China
