TMC-115 is an equivalent to 3M Fluorinert FC-3283 offering similar chemistry and physical properties. TMC-115 is a clear, colorless, thermally stable, fully fluorinated liquid, ideal for use in many single-phase heat transfer applications in the semiconductor manufacturing industry. This makes it an ideal heat transfer fluid for etchers, ion implanters, testers, and others.
TMC-115 is primarily a single compound; its composition will not shift or fractionate with time. This keeps fluid loss to a minimum and insures that heat transfer properties will not change with time.
APPLICATIONS
- Heat Transfer
- Data Center
- Single Phase Immersion Coolant
- Dielectric Bath
- Electronics
- Semiconductor Manufacturing
PHYSICAL PROPERTIES COMPARISON
| PROPERTY | UNITS | TMC-115 |
| Type | Virgin Replacement | |
| Form | Liquid | |
| Color | Colorless | |
| Odor | Odorless | |
| Boiling Point | °C | 110-115 |
| Flash Point | None | |
| Liquid Density (@25°C) | °C | 1.815 g·mL-1 |
| Freezing point(1 atm) | ℃ | -109.7 |
| Critical Temperature | ℃ | 284.7 |
| Critical Pressure | MPa | 5.03 |
| Vapor Pressure(25 ℃) | kPa | 2.426 |
| Latent Heat of Vaporization | kJ·kg-1 | 92 |
| Thermal Conductivity | W∙m-1∙k-1 | 0.0623 |
| Specific Heat (25 ℃) | J·g-1·K-1 | 1.1768 |
| Kinematic Viscosity (25 ℃) | mm2·s-1 | 1.353 |
| Refractive Index | 1.275 | |
| Dielectric Constant(1 MHz) | 1.79 | |
| Surface Tension | mN·m-1 | 15 |
| Coefficient of Volume Expansion (25 ℃) | 0.0014 | |
| Dielectric Loss(1 MHz) | 0.00046 | |
| ODP | 0 | |
| GWP | 120 |
Not for specification purposes. All values @25°C unless otherwise specified.
MATERIAL COMPATIBILITY
TMC-115 is compatible with most metals, plastics, and elastomers.
COMPLIANCE
PACKAGING
- Jug (11 lb / 5 kg / 0.7 gal / 2.75 L)
- Pail (44 lb / 20 kg / 2.9 gal / 11L)
- Drum (551 lb / 250 kg / 36.3 gal / 137.4L)
SHELF LIFE & STORAGE
Shelf life is 60 months from the date of manufacture when stored in the original packaging materials and stored under normal conditions. TMC will re-certify material every 5 years up to 20 years.
DISPOSAL AND RECYCLING
This fluid can be recycled and reused. Help protect the environment, and don't pay for expensive disposal services. TMC Industries can reclaim your used fluorinated fluids, restoring them to like-new condition, and save you up to 50% in replacement fluids while protecting the environment, or TMC will recycle your fluid free of charge (conditions apply).
TMC Reclaimed Fluids are tested to meet new product specifications. It will be clear and odorless, and a Certificate of Analysis is issued with every order.
TMC Industries offers a 100% satisfaction guarantee on all of our reclaimed fluids. We back this up with a no questions asked refund policy. To learn more, click HERE.
